Order PCB layout with placement and routing approvals in the open.

Illuminious is a U.S. NPI engineering company. PCB Layout covers new board layout and controlled modification from your schematic sources and constraints, scoped online and confirmed in a free engineering review. Engineered in San Francisco. Prototype builds, DFM and mass production in our own factory in Shenzhen. Upload your files, get a free engineering review, and pay only the official quote that review publishes.

Our engineers place and route the board from your schematic and constraints. You pick a published tier, approve placement and routing at set milestones, and pay after the free engineering review.

Configure it online, or send the job to an engineer. Online, you get a live supplier price, a published tier, or an official quote prepared by a specialist within 24 hours on business days, depending on the service. Engineering review is free either way and comes before you pay.

Payment: Official price after free review
Review target: Within two business days after you submit

Talk to an engineer Get instant quote

No CAD yet? Our design team can take it from a sketch or a spec.

An engineer reviews every order. Account required before the persistent configurator opens. Engineering review is free and comes before payment, and payment does not authorize production.

Is this PCB layout work, or schematic design?

New layout from completed schematic intent
Controlled layout modification
Dense digital, RF, power, or mixed-signal boards
Projects requiring source and manufacturing outputs

Typical orders: Fixed-scope layout projects and controlled modifications after a reviewed and accepted scope.
Source files: Structured requirements, schematic/source archive, BOM, datasheets/footprints, and mechanical DXF when available.
Accepted formats: ZIP, RAR, 7Z, PDF, PNG, JPG, JPEG, TXT, GBR, GER, GTL, GBL, GTS, GBS, GTO, GBO, GTP, GBP, GKO, GM1, GML, G1, G2, GD1, DRL, XLN, BRD, SCH, PCBDOC, KICAD_PCB, KICAD_SCH, POS, XY, CSV, XLS, XLSX, BOM, DXF, DWG
Payment basis: Official price after free review
Preparation workbook: Download the intake workbook

A shared order lifecycle with service-specific depth.

The configurator collects the factors that drive a responsible preliminary amount. Engineering then reviews the exact source revision, assumptions, and approvals that control release.

Board scope

Define new or modified layout, rigid/flex/HDI/RF/power context, layers, dimensions, pad count, and component sides.

Inputs and tools

Record EDA preference, schematic sources, footprint completeness, mechanical references, and required conversions.

Design constraints

Capture high-speed, impedance, RF, power, thermal, creepage, BGA, placement, connector, and keepout requirements.

Milestone outputs

Select source, Gerbers, BOM/CPL, drawings, 3D outputs, and placement or routing approval gates.

Detail pages for each PCB Layout route.

Each one covers the capability bounds, the pricing factors, and what engineering checks for that specific process or ordering context — and opens the configurator with it already selected.

New PCB layout

New PCB layout from your schematic and constraints. You approve placement before routing starts, and a free engineering review sets the scope first.

Read the detail

Layout modification

Change an existing PCB layout without redoing the board. A free engineering review scopes the change by the nets and areas it actually touches.

Read the detail

How is a PCB layout price built?

Lead time, and what each tier trades

Economy: A longer target lead time than Standard, for work that is not on a deadline. Takes a discount line off the price, never below the service minimum, shown before you commit.
Standard: The lead-time range quoted for your configuration, counted from approved files. No schedule charge. It is the price you were quoted.
Express: Shortens the standard range where the process and the queue allow it. Adds an expedite line, priced on your own configuration and shown before you commit.

Service type, board class, dimensions, layers, pad count, and component sides
Footprint completeness, tool conversion, and mechanical inputs
High-speed, RF, power, thermal, creepage, BGA, and placement constraints
Required outputs, review cycles, approval milestones, and delivery target

Fixed tiers. Engineering review is free and happens before payment, so nothing is charged to reach this figure. Priced from our three published PCB Layout tiers — Starter, Standard, and Premium — confirmed by a specialist during review. Scope is confirmed during review, and the official quote is what you are asked to pay.

What engineering reviews

Customer approvals may include

Official scope and balance after review
Placement milestone when selected
Routing milestone when selected and the final delivery package

Scope completeness and supplied schematic intent
Footprints, datasheets, mechanical envelope, connectors, and keepouts
Electrical, high-speed, impedance, power, thermal, and safety constraints
Deliverables, review cycles, ownership, and milestone acceptance criteria

Free review first. Keep every later decision explicit.

Create your account
Verify your email before the persistent quote workspace opens. Every file, estimate, message, and payment stays attached to that account.
Configure and upload
Provide service-specific inputs and place technical files in private project storage. Saved drafts remain available across sessions.
Free engineering review
Submit the configured cart at no charge. A reviewer checks the exact file and specification revision, then prices it or opens a documented question or correction request.
Official quote
Review publishes an itemized quote with lead time and a validity window. That is the binding figure; anything shown earlier was a preliminary estimate.
Accept and pay
Accepting opens payment rather than charging you. Lead time is counted from settled payment, and any later itemized revision needs your approval first.
Produce and deliver
After all commercial, technical, and customer gates are complete, the project moves through the service-specific production or design milestones.

What this service is intended to produce.

Versioned PCB layout deliverables produced against an approved scope, with explicit placement, routing, and final-package decisions.

Related engineering: Electronics and mechanical product design

Protected and traceable by default

Private files, immutable revisions, authenticated approvals, itemized commercial changes, and customer-visible history are part of the order system rather than a loose email trail.

Boundaries

This route is not schematic design, simulation, cloning, or reverse engineering
Incomplete footprints or constraints may change scope
Fabrication and assembly are separate linked orders unless included explicitly

Answers before you start the workspace.

What is included in PCB Layout?

The service covers placement and routing from supplied schematic intent and constraints, plus the deliverables selected in the order. It does not silently include schematic design, circuit simulation, cloning, or reverse engineering.

Why does layout start with a scoping review?

Pad count, board class, footprint readiness, mechanical data, constraints, outputs and review cycles must be checked before the official scope is known. That check is the free engineering review, and the official quote and its milestones follow it.

How do milestone approvals work?

You can require placement and routing approvals. Each delivery and response is versioned; work advances only after the configured gate is satisfied.

How are source files and ownership handled?

The selected output package and ownership terms are recorded in the approved scope. Files remain private and are delivered through the authenticated project.

Start the PCB Layout price in your private workspace.

Your account preserves drafts, uploads, assumptions, estimate revisions, payments, review questions, and approvals in one project record. An engineer reviews every order.
